| Frame |
TFS - 6061 double butted technoformed aluminium, smooth welding, Boost axle standard, tapered head tube, inboard disc mounts, internal cable routing, BSA BB standard, Max. tyre size 29" x 2.5 |
| Fork |
Suntour XCR34 LOR; Air; 140mm travel; Tapered; lockout; 51mm fork offset. Max. tyre size: 29" x 2.4 |
| Gears |
10 |
| Shifters |
Shimano Deore M4100 with Shimano SL -MT500-IL lever |
| Rear Derailleur |
Shimano Deore M5120 Shadow+ |
| Bottom Bracket |
Shimano Deore |
| Chain |
KMC X10 |
| Chainset |
Shimano Deore M5100; 32 tooth chainset. Crank length: 170mm (S), 175mm (M,L,XL,XXL) |
| Cassette |
Shimano Deore M4100; 11-46 teeth; 10 speed |
| Brake Lever |
Tektro HD-M275 |
| Front Brake |
Tektro HD-M275; 2 piston hydraulic disc brake caliper with Shimano RT10; 180mm rotor |
| Rear Brake |
Tektro HD-M275; 2 piston hydraulic disc brake caliper with Shimano RT10; 180 mm rotor |
| Grip |
Merida Comp EC |
| Handlebar |
Merida Expert CC; aluminium; 740mm wide; 10mm rise |
| STEM |
Merida Comp CC; aluminium; 31.8mm diameter; 6 degree rise - Stem length: 50mm (all sizes) |
| Headset |
Merida M4455 |
| Pedal |
VP Components, VPE-891 |
| Saddle |
Merida Comp SL; V-mount |
| SeatPost |
Merida Comp TR; 30.9mm diameter; in-line; Drop: 125mm (S), 150mm (M/L), 175mm (XL/XXL) |
| Wheel size |
29 |
| Rims |
Merida Comp TR; 29mm inner rim width; Aluminium. Tubeless ready (tubeless tape and valves not included) |
| Spokes |
Black stainless |
| Front Hub |
Shimano MT400-B; 110x15mm; 32 spokes; Center lock |
| Rear Hub |
Shimano MT400-B; 148x12mm; 32 spokes; Center lock; including removable lever with 6mm Allen key |
| Front tyre |
Kenda Regolith; 29" x 2.4"; wire bead |
| Rear tyre |
Kenda Regolith; 29" x 2.4"; wire bead |
| Colour |
Orange |
| Season |
2023 |
